File No. G2296
Perkins Diesel Generator 100KW
Price: Call 519-583-1636 or email sms@scrutonmarine.com
This Perkins diesel generator is suitable for continuous use and has plenty of power for your home, job site, vessel or business. This unit operates at 1800 RPM and with its critical exhaust silencer, deep stiff crankcase, optimized rib arrangement, isolated valve cover and 4-point vibration mounts, runs smooth and quiet.
This unit is fully customizable. From enclosure to fuel tank to controls to trailer, you choose the option that is right for you! And, as an added benefit, you will always have the flexibility to upgrade to other options later.
This Perkins diesel generator features a Perkins 4.4L in-line 4-cylinder diesel engine, turbocharged cooling, direct injection for increased fuel efficiency, low heat rejection and quicker starts, brushless generator end, critical exhaust silencer, automatic voltage regulation (clean power), steel skid base and control panel with hour meter.
Options
- Sound Proof Enclosure
- 100 Gallon Sub-base Fuel Tank
- 250 Gallon Sub-base Fuel Tank
- Double-Axle Trailer
- Remote Monitoring with Gauge Panel
Generator
Is this unit suitable for powering sensitive electronic equipment like a laptop computer? YES
Automatic Voltage Regulation Standard
Electrical Specifications
- Maximum Output 105KW
- Continuous Output 100KW
Power Single Phase
Load Amperage at 120 volts
- Maximum Load 632 Amps
- Continuous Load 602 Amps
Load Amperage at 240 volts
- Maximum Load 316 Amps
- Continuous Load 301 Amps
Power Three Phase
Load Amperage at 208 volts
- Maximum Load 364 Amps
- Continuous Load 347 Amps
Load Amperage at 480 volts
- Maximum Load 158 Amps
- Continuous Load 151 Amps
Load Amperage at 600 volts
- Maximum Load 126 Amps
- Continuous Load 120 Amps
Engine
- Model Perkins 1104-C2
- Combustion System Direct Injection
- Operating RPM 1800
- Number of Cylinders 4
- Cylinder Arrangement Vertical In-line
- Cycle 4 stroke
- Cylinder Block Cast Iron Block w/ Cast Iron Sleeves
- Bore & Stroke 4.21” x 5.09”
- Displacement 4610 cc
- Compression Ratio 18.2:1
- Exhaust Outlet 3” OD Muffler Outlet
- Oil Capacity (w/ Oil Filter) 9 Quarts
- Induction System Turbocharged, air to air charge cooled
- Cooling Water-Cooled
- Coolant Capacity Approximately 13.3 Quarts
- Fuel Number 2 Diesel
- Electric Fuel Pump 12V – Standard
- Fuel/Water Separator Standard
- Cold Weather Starting Aid Glow Plugs
- Starting System Electric
Consumption
- Consumption at ½ Load 3.9 gallons/hour
- Consumption at ¾ Load 5.1 gallons/hour
- Consumption at Full Load 6.1 gallons/hour
Control Panel
- Turn Key Start Standard
- Hour Meter Standard
- Oil Pressure Shutdown Standard
- Engine Overspeed Shutdown Standard
- High Temperature Shutdown Standard
Installation Data
- Fuel Inlet Hose Size ½”
- Fuel Return Hose Size 3/8”
- Power Lead Size No. 2 AWG
- Exhaust Outlet 3” OD Muffler Outlet
- Coolant Recommendation Mixture: ½ Anti-Freeze and ½
- Radiator Dimensions (L x D x H) 26-3/4” x 12”
- Service-Side Direction-Facing Radiator Right Side
- Exhaust Direction-Facing Service Side Front Side
- Fuel Inlet & Return Location-Serv. Side Inlet: Front-Side. Outlet: Front Side
- Power Output Direction-Service Side Right-Side
- Battery Type 12 VDC – 600 CCA – Not Included
- Engine Oil Type 10W-40 Synthetic
Warranty
- Engine Warranty 1 Year
- Generator Warranty 1 Year
- 100% Coverage for Parts & Labor Standard
Dimensions
- Length 88”
- Width 34”
- Height 60”
- Dry Weight 2,130 lbs.
Located in Maine
Details are deemed to be correct but are not guaranteed and should be independently verified.
Please contact us for further information sms@scrutonmarine.com
Scruton Marine Services Phone 519-583-1636 Fax 519-583-2189
